Bar Screen For Sewage Treatment Plant Pretreatment Mechanical Sel
The YMGS/YMHG rotary bar screen is a solid-liquid separation device that continuously and automatically removes sundries from fluid. It is used as primary pretreatment equipment in urban sewage treatment, water supply, power plants, and industrial facilities.
High automation, low maintenance
Self-cleaning rake tooth mechanism
Overload protection with alarm
Low power consumption, noise-free
Model Range
YMGS300-1500 (by width)
Width Capability
Parallel units available for >1500mm
Bar Spacing
1, 3, 5, 10, 20, 30, 40, 50 mm options
Rake Tooth Material
ABS plastic, nylon, or stainless steel
Frame Material
Stainless steel or carbon steel with antiseptic coating
